Key Features and Benefits
- Cooled by premium quality, FDA-approved non-toxic oil.
- Equipped with superior performance ball bearings to ensure durable and long-lasting operation.
- All water-contact components are made of AISI 304 stainless steel, providing excellent corrosion resistance.
- Removable waterproof cable connector for quick and easy maintenance.
- Stators designed for high efficiency and optimal starting torque.
- Pressure-equalizing diaphragm for enhanced reliability.
- All motors undergo 100% testing to ensure quality.
General Specifications
- Mounting flange: 4″ NEMA standard.
- Insulation class: F.
- Degree of protection: IP 68.
- Available power options:
- Single-phase motors: 0.37kW to 3.7kW.
- Three-phase motors: 0.37kW to 7.5kW.
- Motor cable lengths: 1.2m to 3m, depending on motor size.
Operating Parameters:
- Frequency: 50Hz or 60Hz.
- Voltage tolerance: ±10%.
- Maximum ambient temperature: 35°C.
- Minimum cooling flow rate: 0.08m/sec.
- Maximum allowable starts: 40 per hour.
- Maximum operating depth: 300m.
- Suitable for both vertical and horizontal operations.
- Axial thrust load capacities:
- 2000N (0.5 to 1.5 Hp).
- 3000N (2 to 3 Hp).
- 4000N (4 to 5.5 Hp).
- 5000N (7.5 to 10 Hp).
Optional Features:
- Motors available in full AISI 316 stainless steel for higher corrosion resistance.
- Customizable cable lengths.
- Alternative material options available to suit specific requirements.
