Key Features
- Offers a broad range of pump capacities from 1 to 120 m³/h, with customizable stages to suit specific duty points and customer needs.
- 8-inch pumps are currently in development.
- Designed for smooth operation with minimal noise, energy efficiency, and high performance, even under light load conditions.
- All metal components are made of SUS304 stainless steel, except for the pump shaft, which is constructed from high-strength SUS431 stainless steel, ensuring environmental safety and no water contamination.
- Coupled with the motor for easy installation, providing cost savings.
- The high-strength SUS431 stainless steel pump shaft guarantees heavy-duty continuous operation.
- The discharge head features a built-in non-return valve to prevent water hammer, extending the pump’s life cycle.
- The SUS304 strainer restricts sand and foreign material entry, ensuring longevity.
Applications
- Raw water extraction from deep wells (boreholes).
- Pressure boosting for residential buildings.
- Agricultural irrigation and livestock watering systems.
- Municipal and industrial water supply and distribution.
- Fountain applications.
Operating Conditions
- liquid temperature: 86°F
- sand content: 50 gr/m³
Suitable Pumped Liquids
- Clean, thin, non-aggressive, or non-abrasive liquids.
